FS-81R Series Medical Foot Switches (IPX8, Rocker

Features: •Compact design •Pedal rocks left and right for multifunction applications •Various base options available

Installation dimensions:

Specifications: Operating Frequency 60 ops/min Insulation Resistance >100mΩ@500V DC Contact Resistance <25mΩ(initial) Rated Current/Voltage 10A/15A 1/2HP 250VAC Inrush Current Complies with IEC947-5-1: AC15/DC13 Dielectric Strength 1000VAC for 1 min between current carrying parts 2500VAC for 1 min between non-current carrying parts Service Life 1, 000, 000(operations) Operating Temperature -30~+80oC (-22~176oF) Degree of Protection IPX8

TRADEMARK INFORMATION:
All trademarks, trade names, or logos mentioned or used are the property of their respective owners.

TRADEMARK INFORMATION:
All trademarks, trade names, or logos mentioned or used are the property of their respective owners.

TYPE:FS-81R View Details	TYPE:FS-82R View Details	TYPE:FS-81R-W View Details
TYPE:FS-82R-W-B View Details	TYPE:FS-82R-W View Details	TYPE:FS-83R-W View Details
TYPE:FS-81R-SP-W-B3-2-26/7 View Details	TYPE:FS-81R-10W(3-PEDAL)-2-26/7 Black View Details	TYPE:FS-81R-10W(4-PEDAL)-2-26/7 View Details
