ZY-10GW2277 Series Micro Switches

 Features:
 Specifications Operating Speed
0.01mm-1m/sec Operating
Frequency

Specifications:
Operating Speed 0.01mm-1m/sec
Operating Frequency Mechanical: 240ops/min Electrical: 20 ops/min
Insulation Resistance >100mΩ@500V DC
Contact Resistance <15mΩ
Rated Current/Voltage 10A 1/2HP 125/250VAC, 2A 480VAC 0.5A 125VDC,0.25A 250VDC
Dielectric Strength 1000VAC for 1 min between current carrying parts 1500VAC for 1 min between non- current carrying parts
Service Life Mechanically 1 x106 (operations) Electrically 5 x105 (operations)
Operating Temperature -25~+80oC (-13~176oF)
Humidity 35%~85%RH
Degree of Protection general type:IP00 drip-proof type(suffix:-55):IP62
