FSB-6 Medical Footswitches

　Features：
　•Ergonomic low profile design
•Button available 3 to 8
•Easy to clean
•High mechanical stability
•Soft touch button with light operating force

 Specifications:
Operating Frequency 60 ops/min
Insulation Resistance >100mΩ@500V DC
Contact Resistance <25mΩ(initial)
Rated Current/Voltage 15A, 1/2HP, 125/250VAC or 20A 1HP 125VAC, 2HP 250VAC
Dielectric Strength 1000VAC for 1 min between current carrying parts 2500VAC for 1 min between non-current carrying parts
Service Life 1,000,000 (operations)
Operating Temperature 20~+80oC (-4~176oF)
Degree of Protection IP68 (NEMA 4, 4x, 6, 6P)
