FSB-3 Series Medical Foot Switches

　Features：
　•Ergonomic low profile design
•Button available 2 to 3
•Easy to clean
•High mechanical stability
•Soft touch button with light operating force

 Specifications:
Operating Frequency 60 ops/min
Insulation Resistance >100mΩ@500V DC
Contact Resistance <25mΩ(initial)
Rated Current/Voltage 10A, 1/2HP, 125/250VA
Dielectric Strength 1000VAC for 1 min between current carrying parts 2500VAC for 1 min between non-current carrying parts
Service Life 1,000,000 (operations)
Operating Temperature -20~+80oC (-4~176oF)
Degree of Protection IPX8 (NEMA 4, 4x, 6, 6P)
