Foot Switches FS-81-SP-W(Twin)

　Features：
　* Robust Glass Fiber Reinforced Plastics or aluminum die cast body
* Galvanically separated contacts(for FS81-SP only)
* Positive Opening of NC contacts(for FS81-SP only)
* UL/cUL approved (E216958)
* IEC60601 certification issued by TUV for medical applications

Specifications:
Operating Speed: 60ops/min
Insulation Resistance: >100mΩ@500VDC
Contact Resistance: <25mΩ
Rated Current/Voltage: Ith:10A Ui:300VAC
UL Rating:A300/AC15
CCC Rating:10A/250VAC
IEC60601(TUV):5A/25VAC
Dielectric Strength: 1000VAC for 1 min between current carrying parts
2500VAC for 1 min between non-current carrying parts
Service Life: 1,000,000 (operations)
Operating Temperature: -30~+80(-22~+176)
Degree of Protection: IPX8(NEMA 4,4X,6X6P)HR>

SUNS Address:127 Rivemeck Road, Chelmsford, MA01824
Phone:+1-978-349-2329 Fax:+1-978-349-2330　E-mail:info@suns-usa.com
