Interlocking safety switches SND4121(SINGLE CONDUIT ENTRY)

 Features:


Specifications:
Operating Frequency:Mechanical: 120ops/min Electrical: 30 ops/min
Insulation Resistance:>100MW@500V DC
Contact Resistance:<25mW(initial value)
Rated Voltage:300V AC (EN60947-5-1)
Rated Thermal Current:5A
Electrical Rating:AC15 B300 DC13 R300
Dielectric Strength:1000VAC for 1 min between current carrying parts 2500VAC for 1 min between non-current carrying parts
Operating Temperature:-25~+85oC without formation of ice
Humidity:< 95%RH
Degree of Protection:IP67
